Deutsch – DT Series 90° Elbow Swivel Interface
Deutsch – DT Series 90° Elbow Swivel Interface
Single junction straight and 90° elbow fittings providing high integrity connections between Deutsch DT connectors and Harnessflex conduit systems. In addition, 90° elbow versions allow the conduit to swivel 360° around the connector housing, sufficient to avoid the problems associated with one-piece interfaces of overflexing due to movement or vibration.
| Material | High Temperature Polyamide/Nylon |
|---|---|
| IP Rating | IP40 |
| Operating Temperature Range | -40°C to +160°C |
| Short Term Temperature | +200°C (3000 Hours) |
| Long Term Temperature | +185°C (30 000 Hours) |
| Fire Performance | Self Extinguishing / Low Smoke Toxicity / Halogen Free |
| UV Resistance | Very High |
| Colours | Orange (OR) |
